Description
| Feature | Specification |
| Image Sensor | 1/2.8″ 2 MP PS CMOS (0.907 cm) POS Central+12Imimg+12allfortech+12 |
| Maximum Resolution | 1920 × 1080 @25/30 fps ImimgCP PLUS |
| Video Compression | InstaStream, H.265, H.264/H.264H/B, H.264+, MJPEG (sub‑stream) ImimgCP PLUS |
| Stream Capability | Triple stream CP PLUSImimg |
| Lens | 3.6 mm fixed focal (2.8 mm optional), F2.0, M12 mount ImimgCP PLUS |
| Field of View (FOV) | 86° H × 47° V (3.6 mm); 101° H × 54° V (2.8 mm) CP PLUSImimg |
| Minimum Illumination | 0.01 lux (color @F2.0); 0.001 lux (B/W @F2.0); 0 lux with IR ImimgCP PLUS |
| IR/Night Vision | 1× IR LED; smart IR; 30 m range ImimgCP PLUS |
| Day/Night & WDR | True Day/Night (ICR), DWDR/BLC/HLC, 3D NR ImimgCP PLUS |
| ROI & Privacy Mask | ROI (4 areas), privacy mask (4 zones) ImimgCP PLUS |
| Audio | Built-in mic; G.711a/μ, PCM, G.726, AAC ImimgCP PLUS |
| Motion / Smart Detection | Motion detection (4 zones); human & vehicle SMD CP PLUSImimg |
| DORI Distances (3.6 mm) | Detect: 52.4 m; Observe: 21 m; Recognize: 10.5 m; Identify: 5.2 m CP PLUS |
| Shutter Speed | 1/3 s – 1/100,000 s (auto/manual) ImimgCP PLUS |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom ImimgCP PLUS |
| Network & Security | IPv4/IPv6, HTTP/S, TCP/IP, RTP/RTSP, ONVIF S/G/T, SFTP, SNMPv3, TLS 1.2, AES‑256, digital watermarking ImimgCP PLUS |
| Smart Search Support | Compatible with CP Plus Smart NVRs for event extraction CP PLUSImimg |
| Cybersecurity Features | AES‑256 video/config encryption, WSSE, syslog, account lockout, HTTPS, trusted features ImimgCP PLUS |
| OSD & Rotation | Title, date/time overlay; rotation: 0°/90°/180°/270° (1080p or lower) CP PLUSImimg |
| Protocols | DHCP, DNS, RTCP, NTP, SMTP, FTP, ICMP, IGMP, PPPoE, NFS, UDP, SSL, SNMP V3, ONVIF, multicast/unicast ImimgCP PLUS |
| Browser Support | IE, Chrome, Firefox CP PLUSImimg |
| Power | 12 V DC or PoE (802.3af); idle ~1.3 W (DC) / 1.6 W (PoE); max ~3.3 W (DC) / 4.2 W (PoE) CP PLUSImimg |
| Storage Options | Micro‑SD (up to 512 GB), SFTP, NAS CP PLUSImimg |
