Description
| Feature | Specification |
| Image Sensor | 1/2.8″ 2.4 MP CMOS techgurustore.in+9CP Plus+9gatewaycctv.com+9 |
| Resolution & Frame Rate | 1920×1080 (2.4 MP) @25 fps (PAL) / 30 fps (NTSC); 960H on CVBS CP PlusCP Plus |
| Lens | Fixed 3.6 mm (2.8 mm optional); F1.6; angle ~103° diagonal (3.6 mm) / ~126° (2.8 mm) CP PlusCP Plus |
| Illumination | IR & Smart warm-light combined; effective up to 20 m CP PlusCP Plus |
| Night / Day Mode | Full‑color 24/7; ICR-based B/W when necessary CP PlusCP Plus |
| DSP Features | DWDR, 2D-DNR, AWB, AGC, BLC CP PlusCP Plus |
| S/N Ratio | > 65 dB CP PlusCP Plus |
| Privacy Masking | Up to 8 rectangular zones CP PlusCP Plus |
| Video Output | Switchable: CVI / TVI / AHD / CVBS via single BNC port CP PlusCP Plus |
| DORI Range (3.6 mm) | Detect 55.2 m; Observe 22.1 m; Recognize 11 m; Identify 5.5 m CP PlusCP Plus |
| Operating Conditions | –40 °C to +55 °C; < 95% RH (non-condensing) CP PlusCP Plus |
| Power & Consumption | 12 V DC ±30%; max ~3.1 W (white light on) CP PlusCP Plus |
| Ingress Protection | IP67 (weatherproof) CP PlusCP Plus |
| Dimensions & Weight | Ø97 mm × 86.6 mm; ~0.21 kg CP PlusCP Plus |
| Audio | Built-in microphone for synchronized video & audio surveillance CP Plusthehypertech.co |
| Casing Material | Inner core metal + plastic; cover plastic CP PlusCP Plus |
