Description
| Feature | Specification |
| Image Sensor | 1/2.9″ 4 MP PS CMOS (~0.876 cm) YouTube+8Imimg+8etransit.in+8 |
| Max Resolution & FPS | 4 MP (2688×1520) @25/30 fps; downscales to 2560×1440 also supported cpplusworld.comImimg |
| Lens | 3.6 mm fixed-focus (option for 2.8 mm); F1.6; M12 mount; close focus ~1.7 m Imimgcpplusworld.com |
| Field of View | 3.6 mm: H78°/V40°/D93°; 2.8 mm: H94°/V51°/D110° Imimgcpplusworld.com |
| Min Illumination | Color ≥0.06 lux @F1.6; B/W ≥0.006 lux; 0 lux with LED on Imimgcpplusworld.com |
| Night Vision (Illumax) | Dual-light LEDs (IR + warm) providing up to 30 m color/IR visibility; smart IR supported Imimgcpplusworld.com |
| Day/Night Mode | Mechanical IR cut filter (True Day/Night) Imimgcpplusworld.com |
| Video Compression | Instastream, Smart H.264+/H.265, H.264 variants, MJPEG (sub-stream); dual/triple stream modes Imimgcpplusworld.com |
| Image Enhancements | 120 dB WDR, BLC/HLC, 3D‑DNR, ROI (4 zones), digital watermark Imimgcpplusworld.com |
| Shutter Speed | Auto/Manual: 1/3–1/100,000 s Imimgcpplusworld.com |
| White Balance & Gain | Auto, street lamp, outdoor, manual; AGC Imimgcpplusworld.com |
| Audio | Built-in mic; compressions include G.711a/μ, G.726, PCM, AAC cpplusworld.comImimg |
| Privacy & Motion Detection | Motion detection (4 zones), privacy masking (4 zones), mirror support, smart detection (human & vehicles) cpplusworld.comImimg |
| Alarm/Event Triggers | Alerts: network disconnect, IP conflict, illegal access, motion, tampering, audio anomaly, SMD-human/vehicle cpplusworld.comImimg |
| Network & Protocols | RJ45 10/100 Base‑T; IPv4/IPv6; HTTP/S; TCP/UDP; RTP/RTMP; SMTP; FTP/SFTP; DHCP; DNS/DDNS; NTP; ONVIF S/G/T; CGI; SNMP; TLS 1.2; NFS; Genetec/Milestone SDK/API; InstaOn cpplusworld.comImimg |
| Cybersecurity | AES‑256 encryption; HTTPS; WSSE; X.509 cert; trusted boot/exec; account lockout; security logging; IP/MAC filter cpplusworld.comImimg |
| Streams & Bitrate | Triple streams; H.265 bitrate: 3–6144 kbps; H.264: 8–6144 kbps; total bandwidth up to 36 Mbps cpplusworld.comImimg |
| DORI (3.6 mm lens) | Detect: 85 m; Observe: 34 m; Recognize: 17 m; Identify: 8.5 m Imimgcpplusworld.com |
| Power Options | 12 V DC or PoE (802.3af); typical power: 1.6 W (DC)/2 W (PoE); max: 3.7 W (DC)/4.7 W (PoE) cpplusworld.comImimg |
| Power Consumption | Basic: 1.5–1.6 W; Max (LED+WDR+codecs): 3.5–4.7 W cpplusworld.comImimg |
| Environmental Ratings | Operating temp: –40 °C to +60 °C; Humidity ≤95% non-condensing; IP67; metal + plastic housing cpplusworld.comImimg |
| Dimensions & Weight | 162.6 × 70 × 70 mm; weight ≈ 220 g cpplusworld.comImimg |
| Viewing & Software Support | IE/Chrome/Firefox; mobile (gCMOB, iCMOB); CMS (KVMS Pro Lite)Imimgcpplusworld.com |
