Description
| Feature | Specification |
| Image Sensor | 1/2.8″ 2 MP Progressive‑Scan CMOS (0.907 cm) Moglix Documents+8CP PLUS+8Imimg+8 |
| Maximum Resolution | 1920 × 1080 @25/30 fps CP PLUSImimg |
| Video Compression | InstaStream, H.265, H.264/H.264H/B, MJPEG (sub‑stream) CP PLUSImimgAmazon India |
| Stream Capability | Triple stream CP PLUSImimg |
| Lens | 3.6 mm fixed (optional 2.8 mm), F2.0, M12 mount CP PLUSImimg |
| Field of View (3.6 mm) | Horizontal 86°, Vertical 47°, Diagonal 103° CP PLUSImimg |
| Minimum Illumination | 0.01 lux (color), 0.001 lux (B/W); 0 lux with IR on CP PLUSImimg |
| IR/Night Vision | 1 × IR LED, Smart IR, up to 30 m range CP PLUSImimg |
| Day/Night & WDR | ICR auto/manual, DWDR/BLC/HLC, 3D NR, ROI (4), privacy mask (4), digital watermark CP PLUSImimg |
| Shutter Speed | 1/3 – 1/100,000 s (auto/manual) CP PLUSImimg |
| DORI Ranges (3.6 mm) | Detect 52.4 m • Observe 21 m • Recognize 10.5 m • Identify 5.2 m CP PLUSImimg |
| Audio | Built-in mic; G.711a/μ, PCM, G.726, AAC ImimgAmazon India |
| Network & Security | IPv4/6, HTTP/S, TCP/IP, RTP/RTSP, ONVIF S/G/T, SFTP, SNMPv3, TLS 1.2, AES‑256, HTTPS, trusted boot ImimgAmazon India |
| Smart Search Support | Compatible with CP‑Plus Smart NVRs for event search CP PLUSImimg |
| Bitrate Range | H.265: 3–6144 kbps; H.264: 8–6144 kbps CP PLUSImimg |
| Power | 12 V DC or PoE (802.3af); Idle ~1.3 W (DC) / 1.6 W (PoE); Max ~3.3 W / 4.2 W CP PLUSImimg |
| Environmental Rating | IP67; –40 °C to +60 °C; ≤95 % non‑condensing humidity CP PLUSImimg |
| Physical Dimensions | 162.6 × 70 × 70 mm; Weight ~220 g; casing: metal+plastic CP PLUSImimg |
| Certifications | ISO9001, CE, FCC, RoHS, BIS CP PLUSImimg |
