Description
| Feature | Specification |
| Image Sensor | 1/2.9″ 4 MP Progressive‑Scan CMOS (≈0.876 cm) CP Plus+7CP Plus+7Nbts Online+7 |
| Maximum Resolution | 4 MP: 2688 × 1520 @25/30 fps (max); also supports 2560 × 1440, 2304 × 1296, 1920 × 1080, etc. CP PlusImimg |
| Compression Formats | InstaStream, H.265, Smart H.264+/–, H.264H/B, MJPEG (sub‑stream only) CP PlusImimg |
| Video Stream Capability | Triple stream (main + 2 sub‑streams) CP PlusImimg |
| Lens | 3.6 mm fixed‑focal (M12 mount); F2.0 (DA41L3C‑D‑LQ), F1.6 (DA41L3C‑L Flip); optional 2.8 mm CP PlusImimg |
| Field of View (FOV) | 78° H × 43° V (3.6 mm); 92° diagonal CP PlusImimg |
| Minimum Illumination | Color: 0.03 lux @ F2.0; B/W: 0.003 lux; 0 lux with IR on CP PlusImimg |
| IR/Night Vision | 1 × IR LED; 30 m range; Smart IR control CP PlusImimg |
| Smart Warm & Dual Light | DA41L3C‑L version has dual IR + warm‑light (white fill) LEDs (30 m each) Imimg |
| Wide Dynamic Range | WDR 120 dB; BLC, HLC, 3D NR, ROI, privacy mask (4 regions) CP PlusImimg |
| Day/Night & Mirror | Electronic ICR with auto/manual B/W/color; image mirror support CP PlusImimg |
| Audio | Built‑in mic; audio codecs: G.711a/µ, PCM, G.726, AAC CP PlusImimg |
| Audio & Motion Detection | On‑board motion, audio detection; supportive of human/motor‑vehicle SMD CP PlusImimg |
| Video Bitrate | H.265: 3–6144 kbps; H.264: 8–6144 kbps; DA41L3C‑L: H.265: 12–4096 kbps; H.264: 32–4096 kbps CP PlusImimg |
| DORI Ranges | Detect: ~76 m; Observe: ~30 m; Recognize: ~15 m; Identify: ~7.6 m (3.6 mm) CP PlusImimg |
| Shutter Speed | 1/3–1/100,000 s, auto/manual CP PlusImimg |
| White Balance | Supports auto, manual, and preset modes (street lamp, outdoor, region custom) CP PlusImimg |
| Network & Security | HTTP/S, TCP/IP, IPv4/IPv6, RTP/RTSP, ONVIF Profiles S/T, SFTP, NFS, SNMP v3, TLS 1.2, etc.; AES‑256 video & config encryption CP PlusImimg |
| Smart Search | When paired with CP‑Plus Smart NVRs—refined event extraction using SMD CP PlusImimg |
| Cyber Protection | AES 256, WSSE, syslog, account lockout, HTTPS, certificate-based security, trusted boot/update CP PlusImimg |
| Storage Options | Micro SD, FTP, NAS, SFTP (varies by variant) etransit.inImimg |
| Power | 12 VDC or PoE (802.3af); power draw ~1.5 W idle, ~4 W max CP PlusImimg |
| Environmental | Operating: –40 °C to +60 °C; Humidity ≤95 % non‑condensing; IP67 dust/water protection CP PlusImimg |
