Description
| Feature | Specification |
| Image Sensor | 1/3.2″ 2 MP PS CMOS (Ø0.7937 cm) Amazon+75.imimg.com+7Scribd+7 |
| Max Resolution & Frame Rate | 1920 × 1080 @ 25/30 fps (Main); D1/640×480 up to 30 fps (Sub) 5.imimg.comIndustry Buying |
| Lens | Fixed‑focal 3.6 mm, F1.6; M12 mount; close focus ~0.9 m 5.imimg.comIndustry Buying |
| Field of View | H: 87°, V: 47°, D: 102° 5.imimg.comIndustry Buying |
| Illumination | • Color: 0.01 lux @ F1.6 |
| • B/W: 0.001 lux | |
| • Dual-light range: IR up to 30 m, warm light up to 15 m 5.imimg.comIndustry Buying | |
| Day/Night Function | Mechanical ICR auto-switch; dual-light system yields color night vision (“Illumax”) 5.imimg.comScribd |
| Compression & Streams | Smart Instastream, H.264+, H.265, H.264B; MJPEG (sub only); CBR/VBR; bitrates:<br>- H.264: 32–4096 kbps<br>- H.265: 12–4096 kbps Scribd+25.imimg.com+2Industry Buying+2 |
| WDR & Filters | DWDR, BLC/HLC, 3D-DNR, ROI (4 regions), digital watermark 5.imimg.comIndustry Buying |
| Shutter & Exposure | Auto/manual; 1/3 s – 1/100,000 s 5.imimg.comIndustry Buying |
| White Balance & Gain | Auto, natural, street lamp, outdoor, manual; AGC supported 5.imimg.comIndustry Buying |
| Audio | Built-in microphone; G.711a, G.711Mu, G.726, PCM, AAC formats 5.imimg.comIndustry Buying |
| Motion & Privacy Masks | Motion detection with up to 4 regions; privacy masking (4 areas); image mirror supported 5.imimg.comIndustry Buying |
| Network & Protocols | RJ‑45 (10/100 Base‑T); IPv4/IPv6, HTTP, TCP/UDP, ARP, RTP/RTSP/RTCP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ONVIF S/T, CGI 5.imimg.comIndustry Buying |
| Security & Alarms | HTTPS, WSSE, X.509 cert support; trusted boot; encryption; account lockout; logs; events: IP conflict, network disconnect, tampering, audio detection 5.imimg.comIndustry Buying |
| Users & Bandwidth | Supports 6 simultaneous users; total bandwidth up to 24 Mbps 5.imimg.comIndustry Buying |
