Sale!
Categories: cctv camera
CP-UNC-DA21PL3-GP-Y
Login to view prices
-
📷 2MP Full HD Resolution – Delivers crisp 1080p video at 25/30fps
-
🌙 Full-Color Night Vision – Built-in warm LEDs provide vivid color even in complete darkness (up to 30 meters)
-
🎥 Fixed 3.6mm Lens – Offers a wide viewing angle suitable for general surveillance
-
💾 H.265 Compression – Saves bandwidth and storage without compromising quality
-
☁️ InstaOn Cloud Support – Easy remote viewing via CP PLUS mobile apps (gCMOB/iCMOB)
-
🔐 Advanced Security – HTTPS encryption, trusted boot, and user account protection
-
🌦 Weatherproof (IP67) – Ideal for both indoor and outdoor use
-
⚡ PoE & 12V DC – Flexible power options for simplified installation
-
📱 Smart Features – Motion detection, ROI, privacy masking, and 3D-DNR
| Specification | Details |
| Image Sensor | 1/3.2″ 2 MP Progressive Scan CMOS (≈0.7937 cm diagonal) Amazon+13nenizon+13Bestomart+13 |
| Effective Resolution | 1920 × 1080 (Full HD) @25/30 fps nenizonBestomart |
| Minimum Illumination | Color: 0.01 lux @ F1.6 (30 IRE); B/W: 0.001 lux; 0 lux with warm light on nenizonBestomart |
| Lens | Fixed‑focal 3.6 mm (optional 2.8 mm); aperture F1.6; M12 mount; close focus ≈ 0.9 m nenizonBestomart |
| Angle of View | Horizontal ~87°, Vertical ~47°, Diagonal ~102° nenizonBestomart |
| Day/Night & IR | True ICR auto-switch; built-in warm light LEDs (2 units); illumination range up to 30 m (Full‑color at night) nenizonBestomart |
| Compression Format | H.265, Smart H.264+, H.264, H.264B; Instastream support; MJPEG (sub‑stream only) nenizonBestomart |
| WDR & Noise Reduction | DWDR, 3D‑DNR, plus ROI (Region of Interest) support nenizonBestomart |
| White Balance & IRIS | WB: Auto, street lamp, outdoor, manual; Iris: fixed; AGC, BLC, HLC, HLC compensation nenizonBestomart |
| DORI Range | Detect: ~51.9 m; Observe: 20.8 m; Recognize: 10.4 m; Identify: 5.2 m nenizon |
| Shutter Speed | Auto/Manual; 1/3 to 1/100,000 s nenizonBestomart |
| Signal-to-Noise Ratio | > 56 dB nenizonBestomart |
| Streams & Bitrates | Main: 1080p @25/30 fps; Sub: 704×576 @25 fps or 704×480 @30 fps; bitrate H.264: 32–4096 kbps, H.265: 12–4096 kbps nenizonBestomart |
| Protocols | IPv4/IPv6, HTTP, TCP/UDP, ARP, RTP/RTSP/RTCP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, InstaOn cloud, ONVIF Profile S/T, CGI nenizonBestomart |
| Security Features | HTTPS, X.509 cert import, account lockout, WSSE, Trusted boot/upgrade/execution, video encryption & security log nenizon |
| Privacy & Motion Detection | 4 privacy mask areas; motion detection (4 area rectangles); image mirror support nenizonBestomart |
| Storage & Edge | FTP upload support; edge storage via FTP nenizonBestomart |
