Description
| Camera | |
| Image processor | 1/2.7″ cmos sensor |
| Minimum illumination | 0.03 Lux@F2.0 (Color, 30 IRE) 0.003 Lux@F2.0 |
| (B/W, 30 IRE) 0 Lux (IR on) | |
| Image Sensor | 1/2.9″ cmos sensor |
| Shutter speed | 1/50(1/60) to 1/100,000 seconds |
| Angle of view | 3.6mm: Horizontal: 92°; Vertical: 48°; Diagonal: 109° |
| Scanning system | Progressive Scan |
| Lens | |
| Focus Length | 3.6 mm (Fixed) |
| Mount Type / Lens | M12 |
| Focus Control | Fixed |
| Lens Type | Removable |
| Auto Iris | Support |
| Lens | 3.6mm |
| Max. Aperture | F2,0 |
| Night Vision | |
| IR Cut filter | Yes |
| IR Range | 20-25M |
| IR Power On | Auto Control |
| Camera Features | |
| OSD Support | No |
| No of IR LEDs | 4 array IR LED |
| Day/Night | Support |
| Picture Adjustment | Yes |
| WDR | Yes |
| White Balance | Automatic |
| AGC (Gain Control) | Auto / Manual |
| ICR (Infrared Cut Removable Filter) | Auto(ICR)/Color/B/W |
| Back Light Compensation | BLC / HLC / DWDR |
| Video output | |
| Main stream | 2880 × 1620 (1 fps–20 fps) |
| 2688 × 1520 (1 fps–25/30 fps) | |
| Sub stream | 704 × 576 (1 fps–25 fps) |
| 704 × 480 (1 fps–30 fps) | |
| *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.” | |
| Video Compression | H.265 |
| Weatherproof Standard | IP66 Weather-Proof |
| S/N Ratio | >120dB |
| Reset | Yes |
| General | |
| Power Consumption | DC12V±10%, 500mA to 1A / 7.5W to 10W POE |
| Operating Temperature | 10°C ~ +60°C/ Less than 95%RH |
| Weight | 200g |
| Body type | ABS Plastic |
| Dimension (W x D x H) | 7.5 x 17.88 x 6.9 cm |
| Country of Origin | India |
| Package Contents | |
| CCTV Camera | 1 U |
| Mounting Kit | 1 U |
| QR Code User Manual | 1 U |
