Description
| Feature | Specification |
| Image Sensor | 1/3.2″ 2 MP PS CMOS (0.7937 cm) cppluscctvonline.com+11Scribd+11Imimg+11 |
| Resolution & Frame Rate | 1920×1080 @25/30 fps (main stream); D1/704×576 @25 fps or 704×480 @30 fps (sub) ScribdImimg |
| Lens | 3.6 mm fixed focal, F1.6, M12 mount; close focus ~0.9 m ScribdImimg |
| Field of View (FOV) | H: 87°, V: 47°, D: 102° ScribdImimg |
| Illumination | Color ≥0.01 lux, B/W ≥0.001 lux; dual LEDs support IR up to 30 m & warm light up to 15 m ScribdImimg |
| Day/Night Function | Mechanical ICR auto‑switch; dual‑light “Illumax” system for color night vision ScribdImimg |
| Compression & Streams | H.265, H.264, H.264B, MJPEG (sub); Instastream + H.264+; CBR/VBR; bitrate H.264: 32–4096 kbps; H.265: 12–4096 kbps ScribdImimg |
| Image Processing | DWDR, BLC, HLC, 3D‑DNR, ROI, digital watermarking ScribdImimg |
| Shutter Speed | 1/3 s – 1/100,000 s (auto/manual) ScribdImimg |
| White Balance / AGC | Auto, natural, street lamp, outdoor, manual; AGC supported ScribdImimg |
| Audio | Built-in mic; compression: G.711a/μ, G.726, PCM ScribdImimg |
| Motion/Privacy Masks | Motion detection with 4 regions; 4-area privacy masking ScribdImimg |
| Network & Protocols | RJ-45 10/100 Base-T; IPv4/IPv6, HTTP, TCP/UDP, ARP, RTP/RTSP/RTCP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ONVIF S/T, CGI, InstaOn ScribdImimg |
| Security / Alarms | Alarms for network disconnect, IP conflict, tampering, etc.; security: HTTPS, WSSE, X.509, encryption, trusted boot, account lockout, logs ScribdImimg |
| Users & Bandwidth | Up to 6 users; total bandwidth ~24 Mbps ScribdImimg |
| Storage | FTP upload and edge storage ScribdImimg |
| Power Options | DC 12 V or PoE; typical 1.2 W (DC) / 2.1 W (PoE); max ~2.8 W (DC) / 4.0 W (PoE) ScribdImimg
|
